Solar Vehicle Home Off-Grid Photovoltaic Pure Sine Wave Inverter

Product Brief: Rated PowerVoltageNet Dimensions (cm)Net Weight (kg)Packing Dimensions (cm)Packing Weight (kg)AccessoriesShipping Carton Dimensions (cm)1000W12V25*16.5*8.51.431.5*21*161.86mm² Cables (1 set) / Cables24V6mm² Cables (1 set) / Cables48V2.6mm² Cables (1 set) / Battery Car Cables60V2

REQUEST A QUOTE

Description

FAQs

Request A Quote

Description

Rated Power	Voltage	Net Dimensions (cm)	Net Weight (kg)	Packing Dimensions (cm)	Packing Weight (kg)	Accessories	Shipping Carton Dimensions (cm)
1000W	12V	2516.58.5	1.4	31.52116	1.8	6mm² Cables (1 set) / Cables
	24V					6mm² Cables (1 set) / Cables
	48V					2.6mm² Cables (1 set) / Battery Car Cables
	60V					2.6mm² Cables (1 set) / Battery Car Cables
	72V					2.7mm² Cables (1 set) / Battery Car Cables
1500W	12V	30179	1.75	362116	2.3	10mm² Cables (1 set) / Cables	46 * 38.5 * 53.5 (6 units / 13.7kg)
	24V					10mm² Cables (1 set) / Cables
	48V					2.5mm² Cables (1 set) / Battery Car Cables
	60V					2.5mm² Cables (1 set) / Battery Car Cables
	72V					2.5mm² Cables (1 set) / Battery Car Cables
2000W	12V	2717.89.5	2	362116	2.65	16mm² Cables (1 set) / Cables	46 * 38.5 * 53.5 (6 units / 15.8kg)
	24V					10mm² Cables (1 set) / Cables
	48V					6mm² Cables (1 set) / Cables
	60V					6mm² Cables (1 set) / Cables
	72V					6mm² Cables (1 set) / Cables
2300W	12V	31.521.410.4	3	40.52818	3.45	25mm² Cables (1 set) / Cables	59 * 41.5 * 39.5 (4 units / 14.3kg)
	24V					10mm² Cables (1 set) / Cables
	48V					6mm² Cables (1 set) / Cables
	60V					6mm² Cables (1 set) / Cables
	72V					6mm² Cables (1 set) / Cables
	96V	32.721.810.4	3.1		3.55	6mm² Cables (1 set) / Cables
3000W	12V	32.721.810.4	3.1	40.52818	3.55	25mm² Cables (1 set) / Cables	59 * 41.5 * 39.5 (4 units / 16.9kg)
	24V					10mm² Cables (1 set) / Cables
	48V					6mm² Cables (1 set) / Cables
	60V					6mm² Cables (1 set) / Cables
	72V					6mm² Cables (1 set) / Cables
	96V					6mm² Cables (1 set) / Cables
3500W	12V	382510.4	4.05	4630.518	5.1	6mm² Cables (1 set) / Cables	64 * 47 * 39.5 (4 units / 20.4kg)
	24V					16mm² Cables (1 set) / Cables
	48V					10mm² Cables (1 set) / Cables
	60V					10mm² Cables (1 set) / Cables
	72V					10mm² Cables (1 set) / Cables
	96V	3821.810.4	3.6	44.728.217	4.9	10mm² Cables (1 set) / Cables
4000W							64 * 47 * 39.5 (4 units / 20.4kg)
	24V	382510.4	4.05	4630.518	5.1	16mm² Cables (1 set) / Cables
	48V					10mm² Cables (1 set) / Cables
	60V					10mm² Cables (1 set) / Cables
	72V					10mm² Cables (1 set) / Cables
	96V	3821.810.4	3.6	44.728.217	4.9	10mm² Cables (1 set) / Cables
5000W	24V	432510.4	4.9	51.530.518	6	35mm² Cables (1 set) / Cables	64 * 52.5 * 39.5 (4 units / 24kg)
	48V					16mm² Cables (1 set) / Cables
	60V					16mm² Cables (1 set) / Cables
	72V					16mm² Cables (1 set) / Cables
	96V	4321.810.4	4.85		5.7	16mm² Cables (1 set) / Cables

FAQs

How to Choose the Right MPPT Controller Size?

Calculate the required charging current using this formula:

Charging Current (A) = Total PV Wattage (W) ÷ Battery Voltage (V) × 1.25 (Safety Factor)

Example: 800W PV array + 48V battery bank → 800 ÷ 48 × 1.25 = 20.8A → Choose a 20A or 30A controller.
Also, ensure the PV open-circuit voltage (Voc) does not exceed the controller's maximum PV input rating.

What is the Correct Wiring Order?

To avoid damage, follow this sequence strictly:

Connect the Battery first (positive to positive, negative to negative).
Connect the Solar Panels (PV input).
Connect the Load (optional).
Note: Use appropriately sized cables and fuses for safety.

Why is My Controller Not Charging?

PV Voltage Too Low: Ensure the solar panel voltage is at least 5V higher than the battery voltage.
Wiring Issues: Check for reversed polarity, loose connections, or blown fuses.
Battery Full: The controller will taper or stop charging once the battery is full.
Over-temperature Protection: The controller may reduce current if it gets too hot.

What is Temperature Compensation?

A built-in sensor adjusts the charging voltage based on battery temperature. It prevents overcharging in hot weather and undercharging in cold weather, significantly extending battery life.

What is an MPPT Solar Charge Controller?

MPPT (Maximum Power Point Tracking) is an advanced technology that continuously monitors the voltage and current output from solar panels, dynamically adjusting the operating point to extract the maximum available power under varying light conditions. It efficiently converts high PV voltage to the battery’s charging voltage, significantly boosting energy harvest compared to traditional PWM controllers.
